Product Description:

HSD connection system (High Speed Data) ensures fully shielded interconnection, safeguarding against interference and crosstalk. With a characteristic impedance of 100Q, it employs Low Voltage Differential Signaling (LVDS) for data transmission, supporting USD 2.0/3.0, Ethernet, and high shielding demands. Tailored for automotive applications, it facilitates high-frequency signal and data transmission, controlling infotainment, cameras, ports, and displays, with compatibility for LVDS, GVIF, USB, and Ethernet protocols. This enables real-time video images for driving comfort and safety. Designed for modern vehicles, HSD PCB connectors offer reliable data connectivity, coupled with optimized signal integrity, efficient operation, and compatibility with technologies like autonomous driving, contributing to automotive performance and safety.

Features:

1. Primary and secondary locking mechanisms ensure secure connections resistant to vibrations and impacts.
2. High cable retention for crimp connections prevents accidental disconnections and maintains stability.
3. Various codes on the plastic housing provide efficient coding for accurate installations.
4. The fully shielded system is compatible with different wire diameters and types, guarding against interference.
5. High-speed digital data design allows for up to 6Gbps performance, ensuring rapid and reliable data exchange.
6. Lightweight design and right-angle orientation are space-efficient and suitable for PCB mounting.

Technical Parameters:

Applications:

1. Automotive Electronics: Facilitates reliable functioning of various vehicle systems.
2. Digital Infotainment Electronics: Enhances in-car entertainment experiences.
3. LVDS Camera, USB, Ethernet: Supports robust data exchange for cameras, USB interfaces, and Ethernet.
4. Dashboard/Touch Screen: Enables accurate data transfer to interactive displays.
5. Surround Camera: Transmits high-quality video feeds for situational awareness.
6. Vehicle Remote Diagnostics: Exchanges diagnostic data between vehicle and external systems.
7. LVDS Support: Enables high-speed data transmission within automotive applications.
8. Ethernet: Promotes high-speed communication between in-car systems.

HSD Coding:

Customization:

We accept OEM and ODM orders. If you need a different installation, please let us know the type of connector required, and the length of the cable, and we will be happy to consider your request for a working solution. Feel free to contact us.
